UV‑F30 – A Compact 30 cm UV‑DTF Printer for Versatile Printing
The UV‑F30 is a compact A3‑sized UV‑DTF printer designed for high-quality, multi-material printing:
Equipped with two Epson F1080 printheads, it delivers sharp, vibrant results with CMYK + White + Varnish ink. Print widths reach up to 330 mm and speeds up to 1–2 m²/h in 8-pass mode or 0.5–1.5 m²/h in 12-pass.
Built-in LED‑UV cold-curing system ensures energy-efficient, fast curing without heat distortion.
Integrated laminator allows simultaneous printing and lamination in a single pass, simplifying workflow and enhancing durability.
White ink circulation prevents clogging and maintains ink consistency, while air-cooling and precision linear rails ensure reliable operation.
Compatible with AB film and RIP software such as RIIN, FlexiPrint, Cadlink, and MainTop. Dimensions are compact (910 × 949 × 1078 mm) and weight around 60–116 kg.
Perfect for:
Personalized products, small-batch labels/stickers, custom mugs, phone cases, glassware, leather, ceramics, and any flat or slightly curved items.
Why choose UV‑F30?
It delivers vibrant, high-resolution prints on diverse materials, featuring a space-saving design and efficient, automated production for creative studios and small shops.
